Semi-rigid Heat Shrinking Caps Adhesive Lined Under Extreme Operating Condition

Product Description:

1. Structure & Working Principle

Double-layer core structure

• Outer layer: Radiation-crosslinked polyolefin, featuring high mechanical strength, good insulation, flame retardancy, UV resistance and chemical corrosion resistance, which provides the main structural protection for cable terminations.
• Inner layer: Hot melt adhesive (EVA or Polyamide PA as the main raw material), with strong adhesion to metals, plastics and rubber materials.
• Pre-sealed end: One end is pre-shrunk and sealed during production, avoiding moisture and impurity intrusion from the end after installation.

Features:

• Product Name: Dual Wall Heat Shrink Caps
• Highly resistant to common automotive fluids and solvents
• Offers excellent oil resistance insulation
• Low longitudinal shrinkage for precise fitting
• Shrink ratio of 4:1 for versatile applications
• Halogen free for environmentally friendly use
• Ideal for use as double wall heat shrink protection
• Reliable dual wall shrink tubing for enhanced durability
• Contains dual wall adhesive heat shrink tubing for superior sealing

Technical Parameters:

Applications:

• Power & Telecommunications: Sealing protection of cable terminations during laying, storage and maintenance; insulation and moisture-proof of overhead lines, underground cable terminals and distribution cabinet internal wiring.
• Automotive & Rail Transit: Waterproof and oil-proof sealing of wire harness terminals, battery connectors, sensor wire ends and automotive high-voltage wire terminations.
• Electrical Equipment Manufacturing: Insulation and sealing of motor lead-out wires, transformer terminals, generator wiring ends and switchgear internal conductors.
• Renewable Energy & Outdoor Engineering: UV and salt spray resistant protection of photovoltaic cable terminals, wind power tower internal cables and street lamp wiring ends.
• Marine & Offshore Engineering: Corrosion and water-proof sealing of shipboard cables and offshore platform wiring (resistant to seawater erosion and high humidity).
